Trident Therra 5
SKU: TT-GW-0017-MB-01-21-01
Price on request
On/off ground-source and water-to-water heat pump for heating, cooling and domestic hot water. Three-phase, with soft starter, R32 refrigerant, optional passive cooling, Wi-Fi module, cloud-based remote monitoring and BMS communication.
Key features
Questions about this product?
Get in touch with us.
Specifications
The Trident Therra 5 is a high-capacity ground-source / water-to-water heat pump that offers an efficient and stable heating and cooling solution for systems with an available water or ground heat source. Its design also suits industrial, commercial and larger residential applications where high efficiency and predictable operation are the primary concerns.
Reliable output from a ground or water heat source
With 17 kW rated heating capacity and 15 kW rated cooling capacity, the Trident Therra 5 is an ideal choice for buildings with small to medium heat demand. Because the water or ground holds a constant temperature, the system is less sensitive to outdoor conditions and operates stably throughout the year.
Energy-efficient and cost-saving operation
The unit's high COP and EER values allow lower electricity consumption and more favourable running costs. The reliable scroll on/off compressor provides a long service life and dependable operation, while R32 refrigerant is among the proven technical solutions.
Compact design, simple integration
The Trident Therra 5 provides heating, active cooling and domestic hot water in a single compact unit. It is also suitable for passive cooling, which considerably simplifies system design and installation. The solution fits equally well into the building services of new builds and renovation projects.
Who is it for?
The Trident Therra 5 is an ideal choice for:
-
detached houses,
-
smaller apartment buildings,
-
commercial or office buildings,
where a suitable well-water or ground heat source is available. It works well with both underfloor heating and fan coil systems.
Basic data
| Model | Trident Therra 5 |
|---|---|
| Heat pump type | ground-source / water-to-water |
Key features
| Rated heating capacity (W15/W40) | 17 kW |
|---|---|
| Rated power consumption (heating) | 4.2 kW |
| COP | 5.3 |
| Rated cooling capacity (W15/W7) | 15 kW |
| Rated power consumption (cooling) | 3 kW |
| EER | 4.8 |
Heat outputs
| Heating - rated conditions | |
|---|---|
| Heating capacity (W15/W40) | 17 kW |
| Electrical power input | 4.2 kW |
| COP | 5.3 |
| Cooling - rated conditions | |
| Cooling capacity (W15/W7) | 15 kW |
| Electrical power input | 3 kW |
| EER | 4.8 |
Performance data
| Refrigerant | R32 |
|---|
Electrical data
| Rated voltage | 400 V / 3-phase / 50 Hz |
|---|---|
| Max. current draw | 20 A |
Hydraulic data - primary circuit (heat source)
| Heat exchanger type | Plate heat exchanger |
|---|---|
| Water flow rate | 3.6 m³/h |
| Pressure drop | 12 kPa |
| Pipe connection | G1" |
Hydraulic data - secondary circuit (heating/cooling)
| Heat exchanger type | Plate heat exchanger |
|---|---|
| Water flow rate | 3.4 m³/h |
| Pressure drop | 12 kPa |
| Pipe connection | G1" |
Compressor data
| Compressor brand | Panasonic / Copeland |
|---|---|
| Compressor type | Scroll, on/off |
Operating limits
| Max. flow temperature | 60 °C |
|---|
Weight data
| Weight | 125 kg |
|---|
Dimensions
| Width | 650 mm |
|---|---|
| Depth | 620 mm |
| Height | 820 mm |
Noise level
| Noise level | 43 dB(A) |
|---|
